NEW BIK HEAVY LIFT SERIES HL 100T ON PETERBILT 567 6-Axle
 |
NEW BIK HEAVY LIFT SERIES HL 100T
BIK Boom Trucks has grown to service a wide range of customer base, whose industries include the Tree Service Industry, Block/Brick, Pre-Cast, Poured Wall, Building Erection, Crane Service, Oil Field Transportation, Drywall, and many more. After 3000 plus units successfully installed, BIK Boom Trucks has become synonymous with your “One stop shop for all your Boom Truck needs.”
Call Now!
416-679-3838
41 Claireville Drive, Toronto, Ontario M9W 5Z7
Located just 5 minutes north of Toronto International Airport of HWY 427 and Finch Ave. Free airport pick-up for all our guests.
Boom Details
New – BIK “Heavy Lift” Series HL 100T
- PM 100024S Knuckle Boom: 4 Hydraulic extentions to 37’ 5’ horizontal reach (49’ vertical)
- Horizontal Capacity
- 42,400 lbs @ 14′
- 32,100 lbs @ 19′
- 24,010 lbs @25’3″
- 20,600 lbs @ 30’60”
- 16,250 lbs @ 37’5″
- Horizontal Capacity
- PM Power-Link connections at Main, Knuckle & Jib Cylinders, Dual Planetary Gear Motors & Continuous Boom Rotation
- Double pilot operated on slewing and pilot operated check valves on all cylinders
- 180 degree flip-up Hydraulic Extra Wide Main outriggers at pedestal – 28’ – 7” span – 360 degree full load chart stability
- Hydraulic Oil Cooler, high pressure return filter and min. 70 –gallon hyd aluminum oil tank with gate valves mounted at front under deck
- DANFOSS Proportional Control Valve on Boom Column & SCANRECO Proportional Radio Remote Control with back up cord
- Radio Remote includes: 2-batteries, in-cab charger, and back-up cord – 5 level turtle (micro) slow down mode
- Simplified Hydraulic Overload System allowing maximized uptime and ease of maintenance
- Crane Painted PM Blue – Certified Painting Quality System – Load Tested and certified
- Warranty: 1-Yr. part & labour on entire boom, 3-Yr. on Structural Components by PM – 24/7 Crane-Tech Support by BIK
- Installed END OF FRAME, with integral sub-frame, 3/8” front and centre -½” sheer plating at crane for maximized torsion strength.
Deck Details
New – 22′ Long x 102″ Deck with Wooden Surface
- Installed on Truck with 70” of main sill overhang at front for Sub-Frame of Knuckle Boom
- Apitong wood surface
- 60” Headboard ½ smooth steel and ½ expanded metal
- Rub rail both sides with pockets with 8-winches and straps
- Conspicuity Tape and Reflectors
- Headboard and all other steel surfaces primed and painted Gloss black, etc.
Truck Details
New 2024 Peterbilt 567 6-Axle Truck :
- 88,000 lb GVWR
- Cummins 15L Diesel – 565 HP
- Truck cab white, Eaton Ultrashift Plus Automated 18 spd trans
- 22,000 LB fronts with 425 / 65R22.5 tires on Aluminum Rims
- 46,000 LB Rears oon Hendrickson Primax Air- Ride Suspension
- (2) x 13,000 lb self steer lift axle installed ahead tandem with Low Profile 22” tires on alum rims
- (1) – 9,000 lb tag axle (under boom) with low profile 17: tires/alum rims
- Double Frame, Polished ALCOA Aluminium Wheels front and rear, Chrome Exhaust pipe vertical, Chromed Grille & Bumper
- Single 100 gallon alum fuel tank.
Loaded with Options including: A/C, Tilt/Telescopic steering, Top Level Interior, AM/FM/CD player , Jake Brake, air driver’s seat, fixed pass seat, cruise, heated mirrors, exterior S/S sun visor, All-way inter-axle and differential lock-ups, power windows & locks, power mirrors, Air ride cab, full diff locks, trailer air package, etc.
Options Included:
- Auxiliary Extra-Wide hydraulic outriggers 24’ spread front mounted for 360 degree stability at front
- 1” draw plate at rear of truck frame with Pintle Hook and dual rear up/down stabilizers for 100% rearward stability
- Aluminum storage box
- Stabilizer pads with holders at rear bumper and at front sides
Options at Extra Cost:
- (2) additional hydraulic extensions to have 6 total hyd extensions to 53’ reach, Handling 9,300 lb @ 53’
