NEW BIK HEAVY LIFT SERIES HL 100T ON WESTERN STAR 47X 3-AXLE TRACTOR
 |
NEW BIK HEAVY LIFT SERIES HL 100T ON WESTERN STAR 47X 3-AXLE TRACTOR
BIK Boom Trucks has grown to service a wide range of customer base, whose industries include the Tree Service Industry, Block/Brick, Pre-Cast, Poured Wall, Building Erection, Crane Service, Oil Field Transportation, Drywall, and many more. After 3000 plus units successfully installed, BIK Boom Trucks has become synonymous with your “One stop shop for all your Boom Truck needs.”
Call Now!
416-679-3838
41 Claireville Drive, Toronto, Ontario M9W 5Z7
Located just 5 minutes north of Toronto International Airport of HWY 427 and Finch Ave. Free airport pick-up for all our guests.
Boom Details
New – BIK “Heavy Lift” Series HL 100T
- PM 100024S Knuckle Boom: 4 Hydraulic extentions to 37’ 5’ horizontal reach (49’ vertical)
- Horizontal Capacity
- 42,400 lbs @ 14′
- 32,100 lbs @ 19′
- 24,010 lbs @25’3″
- 20,600 lbs @ 30’60”
- 16,250 lbs @ 37’5″
- Horizontal Capacity
- PM Power-Link connections at Main, Knuckle & Jib Cylinders, Dual Planetary Gear Motors & Continuous Boom Rotation
- Double pilot operated on slewing and pilot operated check valves on all cylinders
- 180 degree flip-up Hydraulic Extra Wide Main outriggers at pedestal – 28’ – 7” span – 360 degree full load chart stability
- Hydraulic Oil Cooler, high pressure return filter and min. 70 –gallon hyd aluminum oil tank with gate valves mounted at front under deck
- DANFOSS Proportional Control Valve on Boom Column & SCANRECO Proportional Radio Remote Control with back up cord
- Radio Remote includes: 2-batteries, in-cab charger, and back-up cord – 5 level turtle (micro) slow down mode
- Simplified Hydraulic Overload System allowing maximized uptime and ease of maintenance
- Crane Painted PM Blue – Certified Painting Quality System – Load Tested and certified
- Warranty: 1-Yr. part & labour on entire boom, 3-Yr. on Structural Components by PM – 24/7 Crane-Tech Support by BIK
- Installed END OF FRAME, with integral sub-frame, 3/8” front and centre -½” sheer plating at crane for maximized torsion strength.
Truck Details
New – Western Star 47X tri drive Diesel Tractor: 89,000 lb GVWR
- Truck Cab white in colour
- Cummins Diesel – 500 hp
- 1,700 ft/lb torque
- 18 Ultra Shift Plus Automated transmission.
- 20,000 lb front steer axle with 425/65R22.5 Front Floatation tires on Aluminum rims
- 69,000 LB Rears on air ride Susp with 11R22.5 tires with steel white rims
- Full double frame chassis
- Truck Features Include: Two Stage Engine Brake, Air Cond., AM/FM stereo, power windows & locks, cruise, tilt/telescopic steer column, chrome bumper and grill, heated mirrors and engine block heater, painted ext sun visor, dual chrome vertical tailpipe’s, diff locks with rear wheel lock ups, 5 th wheel with air and electric connections,100 gal aluminum fuel tank, etc…
Options Included:
- Stabilizer Pads (4x) with holders installed at the rear and at the front
- 24” Aluminum storage box installed under the deck
- Front bumper stabilizer
- Rear Auxiliary stabilizers
